Informasjon
Focusrite Scarlett OctoPre Dynamic er en aldri så liten multikunstner. Her får du 8 kanaler mikrofonforsterkere, med kompressorer på hver kanal. Disse kanalene sendes til både de analoge og optiske (ADAT) utgangene, så sant du ikke har trykket på ADAT --> Line-knappen. Da vil nemlig ADAT-inngangene sendes til de analoge utgangene. Focusrite Scarlett OctoPre Dynamic kan derfor også fungere som en 8-kanals DA-converter!
The Scarlett OctoPre Dynamic builds on the features of the Scarlett OctoPre, adding analogue compression to all input channels and eight channels of precision D-A conversion. With dual ADAT* optical I/O, its ideal for expanding a Scarlett 18i8 or 18i20 - or any interface with ADAT I/O.
Scarlett OctoPre Dynamic is the ideal way of adding eight extra mic/line inputs to your DAW. It also offers eight balanced line outputs, sourced directly from their respective mic preamps for use on stage in a live environment.
Scarlett OctoPre Dynamic Key Features
- Eight natural-sounding 2nd generation Scarlett mic preamps
- Flexible analogue compression on every channel
- Eight balanced line inputs
- Focusrite precision AD/DA conversion up to sample rates of 192 kHz
- Dual front-panel instrument inputs
- Optimized headroom for tracking loud sources such as drums
- Eight balanced line outputs - ideal for live use
- Accurate 5-segment LED input metering
- Simple ADAT connectivity via optical cables
- 48V Phantom power available on every channel for condenser mics
- State-of-the-art digital clocking with Word Clock I/O for synchronisation with external devices
Featuring eight channels of Focusrite's 2nd generation Scarlett preamps and a soft-knee VCA compressor on every channel. Scarlett OctoPre Dynamic lets you control the dynamics of all your input signals with an easy-to-use single-knob analogue compressor on every channel. There's a transparent mode for subtle compression plus a "More" button that doubles the ratio for compression with effect.
In addition to the eight input channels, Scarlett OctoPre Dynamic includes eight line outputs, sourced either from the ADAT inputs for eight additional analogue outputs, or directly from the mic inputs for use in a live sound environment.
Scarlett OctoPre Dynamic is ideal for expanding any high quality, multi-channel recording system. With its high-headroom mic, line and dual instrument inputs and analogue compression, it's ideal for tracking drums as well guitars, keyboards, vocals and more. Meanwhile the eight outputs give you the option of expanding your analogue outputs over and above the Scarlett OctoPre
Scarlett OctoPre Dynamic What’s In The Box :
- Scarlett OctoPre Dynamic
- Getting Started Guide
- Power Cable
Produsent
Focusrite
Focusrite deisgner og produserer lydkort, mikrofonforsterkere, analoge equalizere og mye annet.
Spesifikasjoner
Supported Sample Rates
- 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
Microphone Inputs
Frequency Response
- 20Hz - 20kHz +0.5/-1.5dB
Dynamic Range
- 107 dB (A-Weighted)
THD+N
- <0.002%
Noise EIN
- -127 dBu
Maximum input level
- +13 dBu
Gain Range
- 50 dB
Input Impedance
- 3 kΩ
Line Inputs
Frequency Response
- 20Hz - 20kHz +0.5/-1.5dB
Dynamic Range
- 107 dB (A-Weighted)
THD+N
- <0.002%
Maximum input level
- +21 dBu
Gain Range
- 50 dB
Input Impedance
- 64 kΩ
Instrument Inputs
Frequency Response
- 20Hz - 20kHz +0.5/-1.5dB
Dynamic Range
- 107 dB (A-Weighted)
THD+N
- <0.015%
Maximum input level
- +13 dBu
Gain Range
- 50 dB
Input Impedance
- 1 MΩ
Line & Monitor Outputs
Dynamic Range (Line Outputs)
- 109 dB (A-Weighted)
Maximum Output Level (0 dBFS)
- +16 dBu
THD+N
- <0.001%
Ouput Impedance
- 136 Ω (Balanced)
